NX-1300AE3 Analogue Portable Radio (EU use)

Kenwood licensed analogue range of portables, mobiles, base stations and repeaters have been proven in the most extreme situations.

How to buy Share this page Subscribe to newsletter

Multi-protocol radio - designed to operate under digital and FM analogue protocols

64 Channels

7-Colour Light Bar Indicator on the top panel

Internal VOX Function

Voice Annunciation

Built-In Voice Scrambler

QT / DQT, DTMF, 2-tone, 5-tone

2-pin Audio Accessory Connector

Multi-coloured LED	Yes
2-Tone Signalling	Yes
5-Tone Signalling (multi-format)	Yes
Battery Saver Mode	Yes
Busy Channel Lock-out	Yes
Calling Alert	Yes
Compact Design	Yes
Companded Audio	Yes
Data Mode Operation	Yes
Ease of Operating Use	Yes
Embedded Message	Yes
Emergency Call Function	Yes
Emergency Key	Yes
Emergency Advanced Motion Detection Function	No
Enhanced Kenwood Audio	Yes
FleetSync	Yes
Illuminated Keys	Yes
Internal VOX Ready	Yes
Kenwood ESN (Electronic Serial Number)	Yes
Key Beep On/Off	Yes
Key Lock	Yes
Lone Worker Function	Yes
Low Battery Warning	Yes
MDC-1200	Yes
Minimum-Volume Setting	Yes
Monitor Button	Yes
Multiple Scanning Function	Yes
Operator Selectable Tone	Yes
PC Programming & Tuning	Yes
Programmable Function Keys	2 Programmable Function Keys
PTT ID	Yes
QT (CTCSS) / DQT (digital)	Yes
Scan	Yes
Selectable Microphone Gain	Yes
Talk Around	Yes
"Talk Back" Scanning Function	Yes
Time-Out Timer	Yes
Voice Annunciation	Yes
Voice Guide Channel Confirmation	Yes
Voice Inversion Scrambler	Yes
Windows PC Programming and Tuning	Yes

Choice of Optional Battery Packs	Yes
DMR Tier 2 Mode	Yes
NXDN Conventional Mode	Yes

Frequency Range	400 - 470 MHz
Number of Channels	64
Number of Zones	4
Channel Frequency Spread	38 MHz
Channel Spacing - Analogue - Wide/Narrow	25 kHz/12.5 kHz
Battery Life	With KNB-84L: ± 11.0 h With KNB-45L: ± 11.0 h With KNB-53N: ± 7.0 h With KNB-69L: ± 14.0 h - 5-5-90 -
Battery Voltage	7.5 V DC ± 20%
Frequency Stability	± 0.5 ppm (-30 °C to + 60 °C)
Operating Temperature Range	-30 °C to + 60 °C
Dimensions	With KNB-84L: 54.0 x 123.0 x 33.5 mm With KNB-45L: 54.0 x 123.0 x 33.5 mm With KNB-53N: 54.0 x 123.0 x 33.5 mm With KNB-69L: 54.0 x 123.0 x 37.5 mm Radio only: 54.0 x 123.0 x 33.5 mm - Projections not included -
Weight (net)	With KNB-84L : 295 g With KNB-45L : 295 g With KNB-53N : 365 g With KNB-69L : 310 g Radio only : 175 g

Audio Output	1 W (Internal)
Intermodulation	70 dB
Selectivity (Analogue)	25 kHz: 74 dB 12.5 kHz: 67 dB
Sensitivity - EIA 12 dB SINAD	0.26 µV at 25 kHz 0.22 µV at 12.5 kHz
Sensitivity - EN 20 dB SINAD	0.32 µV at 25 kHz 0.33 µV at 12.5 kHz
Spurious Reponse Rejection (Analogue)	70 dB
